Spectra Nova JA 256/80 AAA Print Head

The Spectra Nova JA 256/80 AAA is a high performance, robust and reliable jetting assembly designed for a broad range of wide format printers at resolutions up to 450 dpi. Four electrically independent piezoelectric slices, each with 64 addressable channels, are combined to provide a total of 256 jets. The nozzles are arranged in a single line, at a 0.011 inch distance between nozzles. The fluid interface and electrical connection are at the top of the jetting assembly and several mounting configurations are possible. This jetting assembly contains serial-to-parallel converters for selecting which jets to fire; all jets can be fired simultaneously or individually.

These Spectra heads are manufactured in the US and passed Dimatix Spectra US quality control tests to ensure the best durability. It carries a manufacturer product warranty.

This is the original Vutek print head (number AA90268 and AA90513).

Specifications :

   Technology: Piezo Electric
   Max. Resolution: 450 dpi
   Cal. Droplet Size: 80 pico litre
   Adj. Range for Droplet Size: 70-85 pico litre
   Tot. Amount of Nozzles: 256
   Nozzle Spacing: 279 microns
   Nozzle Diameter: 52 microns
   Firing Frequency: 20 kHz
   Operating Temperature: up to 90°C
   Ink Compatibility: Solvent, water-based and UV Inks

Compatibility :

   Agfa Anapurna 100
   Agfa Anapurna L
   Agfa Anapurna XL
   DGI PolaJet PS-2504
   DGI PolaJet PS-3204
   DGI PolaJet PS-3204D
   DGI PolaJet PS-3206D
   Dilli Neo Plus UVP-1606
   Dilli Neo Plus UVP-1606W
   Dilli Neo Plus UVP-2506
   Dilli Neo Plus UVP-2506W
   Eurotech Eagle S6
   Eurotech Eagle S6²
   Eurotech Eagle S8
   Eurotech Eagle S8²
   Eurotech Malakan
   Eurotech Mermaid
   Eurotech Pars
   HP Fresco 3200
   HP Scitex FB7500
   HP Scitex XP2100 (Expedio 3200)
   HP Scitex XP2300
   HP Scitex XP2500
   HP Scitex XP5100 (Expedio 5000)
   HP Scitex XP5300 (Expedio Revolution)
   HP Scitex XP5500
   HP Tempo
   HP Tempo II UV
   Kornit 931DS
   Kornit Avalanche
   Kornit Avalanche DC Pro
   Kornit Thunder 932
   Kornit Storm II
   Markem-Imaje 5800
   Mutoh Cobra S100UV
   Mutoh Cobra S65UV
   Mutoh Osprey 102
   Mutoh Osprey 130
   Mutoh Osprey 75
   Mutoh PJ-1624NX (Toucan 64 4c)
   Mutoh PJ-1626FE (Toucan Hybrid)
   Mutoh PJ-1626NX (Toucan 64 6c)
   Mutoh PJ-2216NX (Toucan 87)
   Teckwin TeckPro 320
   Teckwin Teckpro H3200
   Teckwin Teckpro H5000
   Teckwin Teckpro S3200
   Vutek UltraVu 150
   Vutek UltraVu II 5330
   DGI PolaJet PS-1804
