CE4 Printhead Assy - M008386

Mimaki CE4 Printhead Assy - M008386

This Printhead Assy is suitable for the Mimaki UJV-160 / JFX / UJF Printers. This is the original Mimaki part (number M008386). It includes the metallic support for fixation. The same printhead without the metallic support is sold as part number KX-CE308644CS-CE4. The cables are 40.9cm long, 2.1cm wide and have 20 pins.

Product Specifications :
    Technology: Multi-drop grayscale micro-piezo
    Grayscale levels: 16
    Active nozzles: 318
    Print swathe width: 53.6 mm
    Nozzle pitch: 169 μm
    Native resolution: 150 dpi
    Printhead weight: 148 g
    Dimensions: 85 x 70 x 23 mm
    Drop volume: 6 - 90 pl
    Typical firing frequency: 2.8 - 28 kHz
    Ink Compatibility: oil-based pigment ink and UV curable pigment ink

Printer compatibility :

   Mimaki UJF-706

   Mimaki UJV-160
